Сервомотор AM8721 с анодированным корпусом предназначен для применения в пищевой, фармацевтической и химической промышленности. Он подходит для приводных решений...
| Номинальное напряжение | 400…480 V AC |
|---|---|
| Standstill torque | 0.50 Nm |
| Rated torque | 0.50 Nm |
| Peak torque | 2.68 Nm |
| Rated speed | 8000 min -1 |
| Rated power | 0.42 kW |
| Standstill current | 0.85 A |
| Peak current | 4.9 A |
| Torque constant | 0.588 Nm/A |
| Rotor moment of inertia | 0.139 kgcm² |
| Motor feedback | OCT, 24 bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplate OCT, 24 bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplate, B/SSD |
| Охлаждение | convection |
| Технология подключения | M23 speedtec ® socket or direct connection for AX5000/AX8000 |
| Ambient temperature (operation) | 5…40°C |
| Допуски/маркировки | CE |
| Конструктивное исполнение | flange-mounted according to IM B5, IM V1, IM V3 |
| Материал | aluminum |
| Coating/surface | anodized |
| b | 9 k6 |
| d | 20 mm |
| l | 63 mm |
| r | 77 mm |
| k (without brake) | 131 mm |
| k (with brake) | 166 mm |
| Информация для заказа / AM8721-WBYZw = 0 | smooth shaft with sealing ring IP69K exclusive shaft feedthrough |
| w = 1 | shaft with groove and feather key according to DIN 6885 and sealing ring IP69K exclusive shaft feedthrough |
| y = G Preferred type | One Cable Technology for power and feedback: feedback transmission via motor cable, no feedback cable necessary, electronic nameplate, single-turn, absolute position within one revolution, resolution 24 bit, SIL 2-capable (mandatory for TwinSAFE Safe Motion functions at AX8xxx-x2xx) |
| y = H Preferred type | One Cable Technology for power and feedback: feedback transmission via motor cable, no feedback cable necessary, electronic nameplate, multi-turn, absolute position within 4096 revolutions, resolution 24 bit, SIL 2-capable (mandatory for TwinSAFE Safe Motion functions at AX8xxx-x2xx) |
| y = L | One Cable Technology for power and feedback: feedback transmission via motor cable, no feedback cable necessary, electronic nameplate, multi-turn, absolute position within 4096 revolutions, resolution 24 bit, SIL 2-capable (mandatory for TwinSAFE Safe Motion functions at AX8xxx-x2xx), Beckhoff Smart System Diagnosis (B/SSD) |
| z = 0 | without holding brake |
| z = 2 | without holding brake, with sealing air connection |
| z = 1 | with backlash-free permanent magnet holding brake |
| z = 3 | with backlash-free permanent magnet holding brake, with sealing air connection |
| c = 0 | motor connection via M23 speedtec ® plug, cable length definable via aaa (1) |
| c = 2 | direct connection for AX5000 up to 25 A (X13+X14), cable length definable via aaa |
| c = 3 | direct connection for AX8000 (X13), cable length definable via aaa |
| aaa | length of the motor cable in decimeters |
